| Model |
Rated power ( W ) |
Rated voltage ( V ) |
Rated rotated speed ( rpm ) |
Startup torque ( N*M ) |
Efficiency |
| LSL-50W |
50 |
DC14 |
200 |
<0.25 |
>70% |
| LSL-100W |
100 |
DC14 |
200 |
<0.35 |
>75% |
| LSL-200W |
200 |
DC28 |
200 |
<0.65 |
>78% |
| LSL-300W |
300 |
DC28 |
200 |
<0.7 |
>78% |
| LSL-500W |
500 |
DC28 |
200 |
<1.2 |
>78% |
| LSL-1000W |
1K |
DC56 |
200 |
<2 |
>88% |
| LSL-2000W |
2K |
DC115 |
200 |
<2.5 |
>85% |
| LSL-3000W |
3K |
DC115 |
300 |
<2.5 |
>85% |
| LSL-5000W |
5K |
AC230 |
200 |
<4 |
>88% |
| LSL-10KW |
10K |
AC230 |
200 |
<6.5 |
>90% |
| LSL-20KW |
20K |
AC400 |
150 |
<15 |
>90% |
| LSL-50KW |
50K |
AC690 |
150 |
<40 |
>90% |
| LSL-100KW |
100K |
AC690 |
140 |
<85 |
>90% |
| LSL-300KW |
300K |
AC690 |
350 |
<185 |
>90% |
|
|
